Harfington Tapered Roller Bearing Inner Cone and Outer Race Cup Set

Tapered Roller Bearing Inner Cone and Outer Race Cup Set

ID:1047154
ID:1047154
Wholesale Price
20%OFF
Order $5000+
  • 20%OFF
    Order $5000+
  • 15%OFF
    Order $2000+
  • 10%OFF
    Order $800+
  • 7%OFF
    Order $500+
  • 5%OFF
    Order $200+
1.78" x 2.89"
SizeName
2
NumberOfItems
About this item
  • Model: LM102949/LM102910 (Bore: 45.242mm / 1.7812", Outer Diameter: 73.431mm / 2.891", Width: 19.558mm / 0.77")
  • Single row tapered roller bearings must be used either with a second bearing or as a matched pair
  • Components are separable and interchangeable that easy for maintenance
  • Features low friction and low noise that provide operational reliability
  • Static Load Rating of 81.8kN and Dynamic Load Rating of 72.9kN
About this item
  • Model: LM102949/LM102910 (Bore: 45.242mm / 1.7812", Outer Diameter: 73.431mm / 2.891", Width: 19.558mm / 0.77")
  • Single row tapered roller bearings must be used either with a second bearing or as a matched pair
  • Components are separable and interchangeable that easy for maintenance
  • Features low friction and low noise that provide operational reliability
  • Static Load Rating of 81.8kN and Dynamic Load Rating of 72.9kN
Specification

Specification

SKU
a19040300ux0883
Cone model
LM102949
Cup model
LM102910
Material
Chrome Steel
Bore diameter
45.242mm / 1.7812 inch
Outside diameter
73.431mm / 2.891 inch
Total thickness
19.558mm / 0.77 inch
Dynamic load rating (cr)
72900N
Static load rating (cor)
81800N
Brand
Uxcell
Inquiry submitted successfully
We will reply within 24 hours during work time. If you haven't received the reply by then, please check your spam. Thank you!
Product Description:

Description:

  • Single Row Tapered Roller Bearings are designed to accommodate combined loads.
  • These bearings consist of an inner ring (cone), an outer ring (cup), a cage and rollers, which distributes radial and loads evenly across the roller.
  • The inner ring with roller and cage assembly (cone) can be mounted separately from the outer ring (cup).
  • The separable components are interchangeable, which facilitate mounting, dismounting and also maintenance inspection routines.
  • This single tapered roller bearing is for use in high-load, moderate-speed applications that include conveyor systems.





Specification:

Cone Model: LM102949

Cup Model: LM102910

Material: Chrome Steel

Bore Diameter: 45.242mm / 1.7812"

Outside Diameter: 73.431mm / 2.891"

Total Thickness: 19.558mm / 0.77"

Dynamic Load Rating (Cr): 72900N

Static Load Rating (Cor): 81800N

$18.25 Regular price
/
Wholesale Price
20%OFF
Order $5000+
  • 20%OFF
    Order $5000+
  • 15%OFF
    Order $2000+
  • 10%OFF
    Order $800+
  • 7%OFF
    Order $500+
  • 5%OFF
    Order $200+
  • Ship from the US
  • In stock, dispatch in 24 hours.
Cart
Cart
Free Shipping over $20 Free upgraded to UPS over $200
By default, UPS or DHL or equivalent express delivery options will be selected, with an estimated delivery time of 4-7 days. Except for remote areas or extremely large volume products.
30 Day Free Return

Description

Description

Description:

  • Single Row Tapered Roller Bearings are designed to accommodate combined loads.
  • These bearings consist of an inner ring (cone), an outer ring (cup), a cage and rollers, which distributes radial and loads evenly across the roller.
  • The inner ring with roller and cage assembly (cone) can be mounted separately from the outer ring (cup).
  • The separable components are interchangeable, which facilitate mounting, dismounting and also maintenance inspection routines.
  • This single tapered roller bearing is for use in high-load, moderate-speed applications that include conveyor systems.





Specification:

Cone Model: LM102949

Cup Model: LM102910

Material: Chrome Steel

Bore Diameter: 45.242mm / 1.7812"

Outside Diameter: 73.431mm / 2.891"

Total Thickness: 19.558mm / 0.77"

Dynamic Load Rating (Cr): 72900N

Static Load Rating (Cor): 81800N
